To assist pioneering mmWave and sub-THz analysis, Rohde & Schwarz continues to roll out superior RF check and measurement options. Three further merchandise tailor-made to W and D band purposes will likely be showcased on the EuMW 2023 in Berlin: The brand new R&S SFI100A wideband IF vector sign generator, the R&S NRP170TWG thermal energy sensor and the R&S FE110ST/SR TX/RX frontends. All three allow researchers to characterize gadgets and circuits for past 5G and 6G cell communications in addition to the novel sensing and automotive radar purposes of tomorrow.
On the European Microwave Week 2023 (EuMW) in Berlin, Rohde & Schwarz will showcase three new product improvements; the R&S SFI100A, the R&S NRP170TWG and the R&S FE110ST/SR. The brand new devices seamlessly complement present cutting-edge RF check options for purposes within the W band (75 GHz to 110 GHz) and D band (110 GHz to 170 GHz) and meet early sub-THz testing wants for past 5G and 6G analysis.
R&S SFI100A wideband IF vector sign generator
Rohde & Schwarz will give a primary demonstration of the brand new R&S SFI100A wideband IF vector sign generator, developed to fulfill bandwidth wants for demanding purposes, similar to early 6G analysis, excessive capability wi-fi backhaul, fastened wi-fi entry, sensing and automotive radar. The compact, user-friendly instrument has a really huge RF modulation bandwidth of as much as 10 GHz and generates absolutely calibrated IF alerts. The R&S SFI100A connects seamlessly with an R&S FExxxST up-conversion frontend to cowl totally different frequency ranges and supply full management of the frontend, letting the answer act as a single instrument. Along with the IF interface, the R&S SFI100A additionally has analog IQ outputs, superb for wideband sign technology within the baseband. On the EuMW, Rohde & Schwarz will present the R&S SFI100A mixed with the R&S FSW50 sign and spectrum analyzer and R&S FE170ST/SR TX/RX frontends to upconvert and downconvert alerts, and the brand new R&S NRP170TWG thermal energy sensor for the D band. Collectively, the devices are a whole and streamlined wideband D band communication testing resolution.
R&S NRP170TWG(N) thermal energy sensor
The brand new R&S NRP170TWG(N) will prolong the thermal RF energy sensors portfolio from Rohde & Schwarz to incorporate the precision measurement of energy ranges within the frequency vary from 110 GHz to 170 GHz. The sensors are available in two fashions; the R&S NRP170TWG (related by way of USB) and the R&S NRP170TWGN (related by way of USB and LAN) and would be the solely plug & play energy sensors in the marketplace for D band measurements. Specification highlights embody a dynamic vary from –35 dBm to +20 dBm, excellent efficiency and wonderful impedance matching. The thermal energy sensors would be the quickest and solely RF energy sensors in the marketplace for the D band that meet mass manufacturing necessities. They’re absolutely appropriate with the opposite D band check options from Rohde & Schwarz.
R&S FE110ST/SR TX/RX frontends
The brand new R&S FE110ST/SR TX/RX frontends prolong the frequency vary of Rohde & Schwarz sign sources such because the R&S SMW200A vector sign generator or the brand new R&S SFI100A wideband IF vector sign generator in addition to the R&S FSW sign and spectrum analyzer to cowl the W band (75 GHz to 110 GHz). They complement the corporate’s portfolio of easy-to-mount frontends. On the EuMW, Rohde & Schwarz will showcase them in a setup of multi-port measurements together with the R&S SMW200A vector sign generator and the R&S RTP oscilloscope.
The three newest additions to the mmWave and sub-THz check portfolio for W band and D band purposes; the R&S SFI100A, R&S NRP170TWG and the R&S FE110ST/SR will likely be accessible quickly from Rohde & Schwarz. Guests to the EuMW 2023 can see them reside from September 19 to 21, 2023, at sales space H105 on the Messe Berlin Hub27.
